Do Reverse Proxies provide real security?

Posted on September 19, 2012 by Pablo Endres

Have you ever questioned the security best practices?

In the process of building / designing the infrastructure for a new project the following question was asked: “shouldn’t we use a reverse proxy to secure or protect the web servers?” Of course the first question I asked myself is “do reverse proxies provide real security?” or is this a best / common practice that has been adopted without foundation?

I worked with some fellow security experts to measure if the use of Reverse Proxies actually provides better security than exposing your web servers directly.

We used the OSSTMM 3 as the basis for the testing so we could measure the Attack Surface. Even though, measuring the Attack Surface with RAVs (the method outlined in the OSSTMM) seems complicated at first, it is actually pretty straight-forward once you understand the concepts.

The results of this research can be found in this paper. It also serves as a good tutorial on how to use the RAVs to measure the security of any scenario.

WebOS Security

Posted on April 23, 2012 by Pablo Endres

I had the pleasure of attending WebOS Developer Workshop in Mainz on Saturday Thgtwi (@thgtwi) did a great job with the organization. SuVuK(@SuVuK_open) did a nice report on the contents of the Workshop in his blog.

I took the opportunity talk about Security in the WebOS platform. I ran some tests based on WebOS 3.X, which is currently available for the HP TouchPad and is being opensourced as Open WebOS. The scope covers issues that can and should be applied to any mobile platform:

Architecture
OS / Platform
Authentication
Networking
Browser
Email
PIM
MDM
Other

I haven’t been able to complete the tests that I wanted to, some of them require Exchange to make use of the EAS policies, which I find interesting to see if the hold up to claims in the WebOS security white paper. I’ll post an update a soon as they are done.

The slides are available under a Creative Commons Attribution-NonCommercial-ShareAlike 3.0 Unported License.

If you have any comments or feedback, feel free to contact me..

Implementing effective controls: Venezuela to block stolen mobile phones

Posted on September 21, 2011 by Pablo Endres

Even though a don’t agree with many of the decisions and laws created in Venezuela, I think this is great example of implementing a control for a big risk.

The Venezuelan telecommunications regulator Conatel, decided that operators have to implement mechanisms to block a mobile phone once reported stolen by its owner. This blacklist, so to speak, should work between the three main operators in the country and they even got RIM (the maker of the Blackberry devices) to agree on blocking these devices world wide.

Here is a link to the story in Spanish.

I remember from when I wrote my thesis back in 2003, that this feature is part of the original design of the GSM system, so these black lists could also be implemented at a worldwide scale. I also have information from a colleague from Romania that this system has been effectively implemented there and has reduced the theft rates dramatically.

So coming back to controlling risks; this measure if implemented correctly should reduce the risk of having a mobile phone stolen because it cannot be sold. The real impact should be seen in a couple of months once enough phones are effectively blocked and the repair shops have enough spare parts (I have no doubts that many stolen phones will be chopped up).

Update 22/01/2012: after a recent visit to Caracas I checked up on this issue. Seams like the actual bureaucratic burden does not let this policy to be correctly be implemented. I hope this gets better with time.

Ubuntu Firefox: This address is restricted

Posted on November 23, 2009 by Pablo Endres

I got the weirdest of errors today trying to open a web page on port 6000:

After reading for a while I found out that de Mozilla Foundation built in this protection for “Cross-Protocol” scripting attack with a form of Port Banning.

To overide this protection use one of the following steps:

In the user’s profile directory the all.js, add the following line at the end of the file user_pref("network.security.ports.banned.override", "1-65535");
In the defaults/pref/ sub-directory of the installation directory (multi-user systems) add the following line at the end of the file user_pref("network.security.ports.banned.override","1-65535");
Open a new window, in the address type: about:config and add a new entry of the type string with this name network.security.ports.banned.override and value 1-65535.

If you want to set free only one port change the range for that port o list of ports.

US Access to SWIFT data

Posted on November 12, 2009 by Pablo Endres

This is a topic that caught my eye a while ago and just found out it’s still an open issue.

According to their website:

SWIFT is the Society for Worldwide Interbank Financial Telecommunication, a member-owned cooperative through which the financial world conducts its business operations with speed, certainty and confidence. Over 8,300 banking organisations, securities institutions and corporate customers in more than 208 countries trust us every day to exchange millions of standardised financial messages.

So basically it’s the organization that manages the API’s and systems that make international banking work smoothly.

This Belgium based organization had it’s major databases in the US until an article in the NY Times aired that the CIA under the Bush administration had been data mining the database to find links to terrorism, after Europe protested the database was move to Holland. So the issue now is that the US intelligence agencies want to keep having unlimited access to spy on EU Citizens using the usual terrorism joker card.

I think this is a big issue and should be handled a such. There are some open questions I have to this deal:
What does a US or in fact any intelligence agency have to do with our financial records without a warrant?
Is every person in the world considered a potential terrorist?
Were are rights, are privacy?
While we’re at it: How long is this data retained? How is it guarded? Who makes sure it’s correctly discarded?

Benjamin Franklin summed this up better than I can ever try to:

They that can give up essential liberty to obtain a little temporary safety deserve neither liberty nor safety

Creating passwords with bash + perl

Posted on September 22, 2009 by Pablo Endres

I had a couple of scripts working in the back end of an application to create users and set the passwords. So instead of reinventing the wheel I used the ?trusty? useradd.

Until recently one could pass the users password in clear text as a parameter. I assume that someone thought about all the passwords that word saved in history files and decided to change it. The problem is that the used the same parameter but now it expected the password to be encrypted, so it basically stopped working but didn’t generate errors.

After some debugging and some man reading the problem was nailed down, but now I had to generate and encrypt the password. I looked and tried many solutions but the best I could find was the crypt library and decided to access is through perl. What I liked the most about the solution is that I could use all the same native algorithms that the system has installed.

So lets cut the chase, here are the 5 lines of code needed to get the job done:

salt=$(/usr/bin/mkpasswd -l 8 -s 0)
parameter=”print crypt(config,\”\\\$1\\\$$salt\”)”
encrypted=$(perl -e “$parameter”)
/usr/sbin/useradd -p $encrypted <user>

To create a good salt I used the mkpasswd utility that comes with the expect package (yum install expect). In this case the $1 is not a variable, but the way of telling crypt to use MD5.

Other valid values for the Glibc crypt are:

ID	Method
1	MD5
2a	Blowfish (not in mainline glibc; added in some Linux distributions)
5	SHA-256 (since glibc 2.7)
6	SHA-512 (since glibc 2.7)

For more information http://www.kernel.org/doc/man-pages/online/pages/man3/crypt.3.html or simply: man crypt

Have fun

ISECOM TtT

Posted on June 15, 2009 by Pablo Endres

I managed to get a few days away from the day job to attend the ISECOM Train the Trainer event in Barcelona (27-29 May) and it was really a great experience. Being that the event was for the certified or to be certified trainer crowd it was pretty intense and at the end of the last day my brain was jello.

Jello Brain

It was great to finally meet Pete Herzog, who I had the pleasure of working with before on the Hacking Expossed book. I also got time to meet some of other European trainers, and it’s a good batch

I got to take the OPSA and OPST exams, the results should be due any time now. I really liked the format of both cert exams: hands on! For the OPST you have to shoot at a couple of live test systems to complete the results you need, and for the OPSA there is a little theory on the OSSTM, some shooting to be done but most of all analysis (hence the A in OPSA). I fried my brain on the last question, I didn’t notice at the begining that it was a packet dump that needed to be analyzed. So after 8 hours of class the 2.5h I took to complete the exam were the last effort.

For those of you who have no idea of what I’m talking about, you can find information on the OSSTM at http://www.isecom.org/

GnomeKeyring =? ssh-agent

Posted on May 5, 2009 by Pablo Endres

This feature just popped up and started working after I upgraded to Fedora 10 and I though it was a standard function in gnome, but I was working with Per the other day and his Ubuntu 8.04 didn’t have it running out of the box. So I had to take a look a the docs to make it work: http://live.gnome.org/GnomeKeyring/Ssh

This is just one of those features that make your life easier but handling all the ssh sessions for you, the best part is that is one of those setup once and forget feature. Here is a brief introduction on how it works:

According to the ssh-agent man:

     ssh-agent is a program to hold private keys used for public key authenti-
     cation (RSA, DSA).  The idea is that ssh-agent is started in the begin-
     ning of an X-session or a login session, and all other windows or pro-
     grams are started as clients to the ssh-agent program.  Through use of
     environment variables the agent can be located and automatically used for
     authentication when logging in to other machines using ssh(1).

So what gnome did was include an ssh-agent in the gnome-keyring(-daemon), so it has one interface to manage passwords, ssh keys, etc. Underneath the hood this is how it works:

When Gnome starts the gnome-keyring-daemon (if it is enabled in your conf)
The keyring manager starts the ssh-agent component and sets up the SSH_AUTH_SOCK variable, that will redirect ssh to make the queries to that socket
The SSH agent automatically loads files in ~/.ssh having names starting with id_rsa or id_dsa or any other keys included by using the ssh-add command

That does the job. If you need to get it working on your Gnome installation follow the instructions here.

snmp errors in syslog

Posted on April 19, 2009 by Pablo Endres

I finally got fed up of these messages in my log files (/var/log/messages) and decided to do something about them:

Apr 19 04:14:47 hostname snmpd[3458]: Connection from UDP: [127.0.0.1]:42482
Apr 19 04:14:47 hostname snmpd[3458]: Received SNMP packet(s) from UDP: [127.0.0.1]:42482

After reading, googling around and testing for a while I rounded it the following solution, it should work in any Linux system with net-snmp after some tweaks but out of the box on CentOS, REL, Fedora or any of its relatives:

1. Remove the -a from the snmpd start options or write this in the /etc/sysconfig/snmpd.options file:

OPTIONS=”-Lsd -Lf /dev/null -p /var/run/snmpd.pid”

This should take care of the “Received SNMP” packets line (2nd one).

2. Add dontLogTCPWrappersConnects true at the end of your /etc/snmp/snmpd.conf file, that takes care of the other line:

Apr 19 04:13:47 dcf-is1p snmpd[3458]: Connection from UDP: [127.0.0.1]:48911

According to the man page: This setting disables the log messages for accepted connections. Denied connections will still be logged.”

The problem is that the default settings are to log every connection / request, so what we did was leave the log work only for failed and authenticated attempts

Enjoy readable logs!

Changes to the data collection law in Germany

Posted on November 10, 2008 by Pablo Endres

I’ve been living in Germany for a little more than a year now, and since then lots of things have really impressed me in the way privacy, digital rights, data collection, infomation security are managed in politics.

There have been some major attempts to create a state of surveillance protect the people and the institutions from hackers, terrorists in exchange for freedom and civil liberties. Let’s take for example the Skype Trojan they intented to create and use out in the wild without warrants, the prohibition of “hacker tools” or the data collection law.

After giving a big fight, last week the court in Karlsruhe ruled that:

Data can only be collected when the stability or security of Germany or another country need to be defended and “life, limb, and freedom of German citizens” need to be protected (The Register)

I think this is a mayor advance, and I really hope this will be followed by action in the other controversial laws.
